MPMC HBD Series

3000 cycle life

<3hr Fast Recharge

Zero Emission

Low Noise

The system capacity of this HBD battery energy storage system is up to 2500kWh. And we also design a specific silent canopy for the BESS with a capacity below 100kWh.
UN 38.3     MSDS       UL 1973               UL 9450A           UL 1741                UL / IEC 62109-1       IEC / EN 61000-6-4
IEC / EN 61000-6-2        CISPR 11 / EN 55011            FCC Part 15 Class A            IEEE Std C37.90.2
Details
Controller
Battery Rack
Removeable lifting holes
Fire-proof
Battery Pack
Forklift holes
Your Clean Energy Solutions
Resiliency Security Money Saver
MPMC built-in EMS and PCS present a powerful and effective solution in helping the operators decide on power source priorities under different load demands, and functioning critical loads and other loads independently.
From generating and absorbing power, to  regulating real and reactive power quality, MPMC HBD Series energy storage system serve a variety roles within a micro-grid as both prime power and backup power.
It is perfectly compatible with solar power, wind turbines, diesel generators and gas generators, on & off grid.
Customer Self-Supply

If you are a small / medium business owner, or a householder who’s ready to go green, MPMC HBD Series Energy Storage System will be your best bud.

MPMC built-in EMS allows operators to run loads through PV or other hybrid energy systems and store the extra power in LiFePO4 battery storage system,  which greatly reduces the dependence on grid utility and lowers the cost of electricity consumption with peak power shaving.
Power More
  • Backup Power
    MPMC HBD Series have been a proven solution for grid stabilization functionalities such as Contingency Reserve, islanding and microgrid ready capabilities, utility power emergencies etc. The response time can be lower than 20ms during power outages.
  • Quiet Power
    MPMC HBD Series make the best case of power generation solutions for public services. They can be fully charged less than 3 hours and discharge to generate stable electricity for 9 hours with ≤ 5 dBA noises and 0 emissions.
  • Impact Load
    Applying diesel generators for power sectors like mobile cranes, urban electric vehicle charging stations could end up in shortening the service life of the generator sets for engine habits of impact load leads to carbonisation, high fuel consumption and possible fuel leakage as they serve at low load (0% - 30%) for most of the time. MPMC HBD Series help to improve the lifespan of diesel generator sets and power generation efficiency.
Applications

Micro Battery Energy Storage System


Model HBD-30-60 HBD-45-45 HBD-50-50 HBD-50-100 HBD-100-100
Rated Power 30kW 45kW 50kW 50kW 100kW
Rated Voltage 400Vac 400Vac 400Vac 400Vac 400Vac
Frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz
Phase 3 3 3 3 3
System Energy Capacity 62.7kWh 46.08kWh 53.8kWh 98.6kWh 98.6kWh
Battery Type LiFePO4 LiFePO4 LiFePO4 LiFePO4 LiFePO4
Dicharge Depth 0.9 0.9 0.9 0.9 0.9
Pack Qty. 7 9 6 11 11
Cooling System Fan Fan Fan Air Conditioner Air Conditioner
Cycle Life 3000 3000 3000 3000 3000
Operating Altitude ≤1000 ≤1000 ≤1000 ≤1000 ≤1000
Operating Temperature -20°C~50°C -20°C~50°C -20°C~50°C -20°C~50°C -20°C~50°C

Containerized Battery Energy Storgae System



Model HBD-100-200 HBD-150-150 HBD-150-300 HBD-250-426 HBD-250-500 HBD-500-1000 HBD-1000-2500
Rated Power 100kW 150kW 150kW 250kW 250kW 500kW 1000kW
Rated Voltage 400Vac 400Vac 400Vac 400Vac 400Vac 400Vac 400Vac
Frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz
Phase 3 3 3 3 3 3 3
System Energy Capacity 200.7kWh 150.5kWh 301.1kWh 426.5kWh 526.8kWh 1004kWh 2559kWh
Battery Type LiFePO4 LiFePO4 LiFePO4 LiFePO4 LiFePO4 LiFePO4 LiFePO4
Dicharge Depth 0.9 0.9 0.9 0.9 0.9 0.9 0.9
Pack Qty. 16 12 24 34 42 80 204
Cooling System Fan Fan Fan Air Conditioner Air Conditioner Air Conditioner Air Conditioner
Cycle Life 3000 3000 3000 3000 3000 3000 3000
Operating Altitude ≤1000m ≤1000m ≤1000m ≤1000m ≤1000m ≤1000m ≤1000m
Operating Temperature -20°C~50°C -20°C~50°C -20°C50°C -20°C~50°C -20°C~50°C -20°C~50°C -20°C~50°C
